Input Voltage:
80~264Vac
Output Voltage:
19Vdc
Output Max Current:
4.74 Amps
Max Power:
90 Watts
Features
AC input range: 80~264Vac
Operating temperature: -30~+70°C
Medical safety approval: ANSI/AAMI ES60601-1, IEC60601-1
2xMOPP - Means of Patient Protection (between primary to secondary)
Energy efficiency Level VI
Low no load power consumption: <0.15W
Low leakage current<100uA
High efficiency
LED indicator for power on
AC inlet: IEC320-C14
DC output connector: 2.5x5.5mm center positive, tuning fork type, -V connected to AC FG
Protections: short circuit / over load / over voltage / over temperature
