Erica Synths Fusion VCO

Price:
$550.00
Brand:
This product is available for pre-order only

Click the button below to add the Erica Synths Fusion VCO to your wish list.

SHARE

Product Description

Erica Synths Fusion VCO is special kind of VCO – it fuses great tuning of digital VCO with warm, unique sound of vacuum tubes that work in suboscillator circuit.



Two double triodes in bistable latch connection act as suboscillators: -1 and -2 octaves with plenty of mixing opportunities for amazing sonic results. External audio signal can replace internal VCO. If you wish to go really low frequencies and have a sound that sets your modular system apart from mass – this is exactly module, you need!

      Features:
  • 3 basic waveforms (sine, triangle and pulse) with VC morphing, for example, triangle morphs from sawtooth to ramp
  • Good 1V/oct tuning for 8 octaves
  • Vacuum tube based suboscillators -1 and -2 oct
  • Manual and CV controlled -1/-2 oct mixing
  • Adjustable suboscillator waveshape
  • Dry/Wet (VCO/suboscillators) mixing
  • Passive Lowpass filter for extreme subbass sound
  • Audio input



Technical specifications:

Audio input signal level

up to 20V ptp

Output signal level

10V ptp

VCO range

C1 – C8

Power supply

bipolar +-12V , eurorack standard and Erica Synths 6VAC PSU

Power consumption

Tube heater PSU configuration: 60mA@+12V, 30mA@-12V, 300mA@6VAC

Eurorack PSU configuration: 215mA@+12V, 185mA@-12V       (NB – start-up power consuption for few seconds is +-250mA)

Module width

24HP

Module depth

35mm





Product Videos

Erica Synths Fusion VCO demo (08:42)
Fusion VCO fuses good tuning of digital VCO with warm, unique sound of vacuum tubes that work in suboscillator circuit. More: http://www.ericasynths.lv
  • Erica Synths Fusion VCO demo
    Fusion VCO fuses good tuning of digital VCO with warm, unique ...
  • Erica Synths Fusion Drone System
    Fusion Drone System is tube based eurorack modular synth desig...
