Product Overview
The RS-380 is a composite module comprising four separate ‘sub-modules’ that you can patch together or with other RS Integrator modules to generate and control a wide range of effects.
It is designed for use when space is at a premium, and combines a flexible Voltage Controlled Low Frequency Oscillator (VC-LFO) with a noise generator, a Voltage Controlled Amplifier (VCA) and a random signal (sample & hold) generator.
Voltage controlled LFO with two selectable frequency ranges: LOW goes from 0.3Hz to 6Hz and HIGH from 5Hz to 1.500Hz; using control voltages you can reach lower and higher frequencies, though. The CV input is not compliant to the 1V/octave characteristic. Two waveforms are available: square and triangle.
Analog noise generator that produces white noise.
Sample & Hold: due to normalized sockets you can use this sub-module without patching as the LFO´s square wave and the white noise are pre-patched. Alternatively you can insert other signals than the internal white noise through the Source In socket.
VCA: classic VCA with one signal input, two signal outputs and one CV input.
