Flame Airlectron Sensor Recorder

The AIRLECTRON is a small, compact CV module with a distance sensor and recording function. The module can record the CV generated by hand movement over the sensor up to a length of more than two minutes. The sequence remains stored in the battery-backed RAM even after switching off.

There is a HOLD function to hold the CV at the current position above the sensor. Additionally, a GATE is set when the sensor is triggered. A START/RESET input is used to reset/start recording/playback.

The voltage generated is available at two CV outputs, bipolar from approx. +/-5v and unipolar from approx. 0 to +10v. Both outputs have a passive attenuator so that the voltage range can be set lower.

The RANGE control is used to set the distance range (up to approx. 40 cm) of the distance sensor. The sensor is independent of external light and provides a logarithmic voltage curve with 12-bit resolution.
