DAVE JONES DESIGN O'TOOL PLUS

The O'Tool Plus from Dave Jones Design is an oscilloscope

and set of visual audio tools. It is an improved version

of the original O'Tool module. It includes:

- Single channel oscilloscope

- Dual channel oscilloscope

- 3D oscilloscope

- X/Y display

- Level meter

- VU meter

- Peak meter

- Voltmeter (with p-p and average DC)

- Frequency meter

- Tuner (guitar tuner style)

- Linear spectrum analyzer

- Log spectrum analyzer

- Spectrogram

- BPM meter

- Metromome

It includes user configurable settings and can remember

settings at power up for three users. That means you can

have different settings for home, studio, and performances,

or any three different sets of settings.

It is temperature stable and extremely accurate. It can

monitor two signals, with inputs looped through to other

modules. The scope modes include an external trigger option.

It is firmware upgradable. It has a jumper for internal

or external 5 volt source. It has an expansion connector

for possible future add-on modules.

Power requirements:

80ma +12v

22ma -12v

-or-

12ma +12v

70ma +5v

22ma -12v

Width: 8HP

Depth: 40mm
